2019 Orange Alpine 6 Pro Full Suspension Mountain Bike - Silver

Season:2019

Brand:Orange Bikes

Code:B19ALPPRO

The Alpine 6 is the de-facto big mountain leveller. Engineered to perform in the roughest mountain terrain.

The Alpine 6 geometry is designed around 170mm front/160mm rear travel. With its slacker 64.5° head angle matched to the 170mm fork we get that alpine handling feel we all love; confident, unflappable and most importantly, fun.

With neat finishing touches like internal cable routing, every element of the frame’s construction has been analysed and optimised, to the point that, size for size, the Alpine 6 frame is significantly lighter and stronger than its predecessors.

One of our most popular models and it's easy to see why. Whether in the heat of competition, or simply being ridden for laughs, the Alpine 6 has that spirit we love in a bike, the ability to surge through the rough stuff and rewards the rider that pushes hard.

WHY THE ALPINE 6?



  • Frame designed and built in Britain
  • 5 year frame warranty
  • Single-pivot suspension for optimum performance, efficiency and reliability
  • 27.5" tubeless ready wheelset
  • Boost 148 rear hub spacing
  • Alpine-trail honed geometry
  • Long top tube and wheelbase coupled to a shorter stem for high-speed stability
  • Unique monocoque aluminium and tubing chassis
  • 170mm Front/160mm rear travel​
  • Choose from ten custom colours
  • Customise your Alpine 6 with our huge selection of optional upgrades
Technical Information



Frame & Fork
Tubeset 6061-T6 Monocoque UK Formed Custom Aluminium Tubing
Fork Fox Performance 36 Float 170mm 27.5
Rear Shock Fox Float DPX2 Performance 216x63
Headset Cane Creek 49mm For Tapered Steerer
Rear Axle Bolt Type Allen Key Head (Boost 148mm Hub)
Wheels & Tyres
Wheelset Kore Realm 3.0 on Joytech 27
Tyres Maxxis DHR II 2.4 Exo TR 27.5
Drivetrain
Crankset SRAM Descendant 6K Dub
Chain Device Not Included
Rear Mech SRAM GX Eagle 12spd
Cassette SRAM NX Eagle 1230 11-50T
Shifters SRAM NX Eagle 12spd
Bottom Bracket SRAM DUB
Chain SRAM NX Eagle
Braking
Brakes Shimano SLX 203/180
Finishing Kit
Stem Race Face Chester M35 x 40mm
Handlebar RaceFace Chester 780mm M35
Grips Strange 130 Lock - On Grips Black
Seatpost SDG Tellis
Saddle Kore Conex
Seat Clamp Strange QR
Pedals Not Included



Sizing Information
2017-18 Alpine 6 Geometry
ALPINE 6 GEOMETRY
Monocoque/6061-T6 Custom Butted Aluminium tubing
Frame Size XS S M L XL
Seat Tube Length 15" 16" 17" 18" 20"
A. Head Angle 64.5° 64.5° 64.5° 64.5° 64.5°
B. Seat Angle (Actual) 72° 72° 72° 72° 72°
B. Seat Angle (Effective) 74° 74° 74° 74° 74°
C. Top Tube 555 575 594 614 634
D. Top Tube (effective) 580 600 620 640 660
E. BB Height (from ground) 342 342 342 342 342
BB height (from axles -12 -12 -12 -12 -12
F. Chainstay 430 430 430 430 430
G. Head Tube 100 120 120 125 130
H. Wheel base 1168 1190 1210 1231 1253
J. Reach 409 423 443 461 478
K. Stack 600 618 618 622 631
T. Rear Travel 160 160 160 160 160
Standover 713 730 745 758 792
Unless otherwise indicated all measurements are in mm. Frame angles are measured static, without rider sag. Bottom bracket height measured from ground with 715 mm Ø tyre.
