Frame | Moterra LT Carbon, 27.5” rear wheel, 29” front wheel, 165mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148×12mm thru-axle,UDH, 200mm native post mount brake, 1.5” – 1.8” tapered headtube |
Fork | Fox Float Performance 38, 170mm, Grip Damper 3Pos, 15×110mm Kabolt thru-axle, tapered steerer, 44mm offset |
Headset | FoxDHXPerformance, Coil, 2 pos adj, 230×65mm |
Rear Shock | FoxDHXPerformance, Coil, 2 pos adj, 230×65mm |
Drive Unit | Bosch Performance Line CX 5 |
Battery | Bosch PowerTube, 800Wh |
Charger | Bosch 4A |
Display | Top Tube System Controller w/ Mini Remote |
Rear Derailleur | SRAMEagle 90, T-Type |
Shifter | SRAMEagle 90, T-Type, 12-speed |
Chain | SRAMEagle 70 T-Type, 12-speed |
Crank | e*thirteen e*spec Helix Core, 55mm chainline, 160mm, 34T |
Cassette | SRAMEagle 70 T-Type, 10-52, 12-speed |
Brakes | TRPEVOPro 4-piston hydraulic disc, 220/203mm rotors |
Rims | DT Swiss H 1900 Spline, 30mm inner width, TC (tubeless ready) |
Spokes | DT Swiss Competition, straight pull |
Front Hubs | DT Swiss 370, 15×110mm thru-axle |
Rear Hub | DT Swiss 370 Ratchet System 18, 12×148mm thru-axle, 6-bolt |
Front Tyre | Schwalbe Shredda Front, 29×2.5”, Radial casing, Addix Ultra Soft Foldable , tubeless ready |
Rear Tyre | Schwalbe Albert, 27.5×2.5”, Radial casing, Addix Soft Foldable, tubeless ready |
Handlebar | Cannondale 3 riser, 6061 Alloy, 25mm rise, 8° sweep, 4° rise, 800mm |
Stem | Cannondale 1, 6061 Alloy, 35.0, 40mm, 0° |
Grips | Cannondale TaperRidge |
Saddle | Fizik Terra Aidon X5, 145mm, Wingflex, S-Alloy Mobius rail |
Seatpost | Cannondale DownLow Dropper, internal routing, 34.9, 150mm (S), 170mm (M), 200mm (L), 230mm (XL) |
