FRAME
Specialized M5 Premium Aluminum, 27.5 Trail Geometry, integrated down tube battery, enclosed internal cable and Command Post IR routing, 148mm spacing, fully sealed cartridge bearings, 180mm of travel
FORK
RockShox Lyrik RCT3, 27.5", Dual Position Air, Boost 15x110mm, 35mm stanchions, 180mm of travel
REAR SHOCK
Öhlins TTX22M, Coil
FRONT HUB
Specialized, sealed cartridge bearings, 15x110mm spacing, 24h
REAR HUB
Specialized alloy disc, sealed cartridge bearings, 12x148mm, 10-/11-speed freehub, 28h
SPOKES
DT Swiss, stainless
RIMS
Roval Traverse 27.5, hookless alloy, 38mm inner width, tubeless ready, 24/28h
INNER TUBES
27.5 x 2.3" / 3.0", 40mm Presta valve
FRONT TYRE
Butcher, GRID casing, Gripton compound, 2Bliss Ready, 27.5 x 2.8"
REAR TYRE
Butcher, GRID casing, Gripton compound, 2Bliss Ready, 27.5 x 2.8"
CRANKSET
Custom alloy crankarms
CHAINRINGS
Forged steel, 32T
SHIFT LEVERS
SRAM GX, one-click shift-lever
REAR DERAILLEUR
SRAM GX, long cage, 11-speed
CASSETTE
SRAM PG-1130, 11-speed, 11-42t
CHAIN
KMC X11ET, 11-speed w/ Missing Link™
FRONT BRAKE
SRAM Code R, hydraulic disc, 200mm
REAR BRAKE
SRAM Code R, hydraulic disc, 200mm
HANDLEBARS
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 780mm width
GRIPS
Specialized Sip Grip, half-waffle, XS/S: regular thickness, M/XL: XL thickness
STEM
Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Command Post Wu, S/M: 125mm of travel, L/XL: 150mm, 34.9mm, 8mm offset
SEAT BINDER
Alloy, 38.6mm
MOTOR
Specialized 1.3, custom Rx Trail-tuned motor, 250W Nominal
UI/REMOTE
Trail Handlebar Remote, motor mode switch & walk-assist
BATTERY
Specialized M1-504, integrated Trail Display, ANT+/Bluetooth® module, 504Wh, Mission Control App connectivity
CHARGER
Custom charger, 42V4A with Rosenberger plug
WIRING HARNESS
Custom Specialized wiring harness
PEDALS
Specialized Platform, Cr-Mo axle, PP-Body
