FRAME
Specialized M5 Premium Aluminum, 27.5 Trail Geometry, integrated down tube battery, enclosed internal cable routing, 148mm spacing, fully sealed cartridge bearings, 180mm of travel
FORK
RockShox Yari RC 27.5", Boost™, 15x110mm, 180mm of travel
REAR SHOCK
FOX Van RC Coil, S: 400 lb/in, M: 450 lb/in, L: 500 lb/in, XL: 550 lb/in, 216x57
FRONT HUB
Specialized, sealed cartridge bearings, 15x110mm thru-axle, 28h
REAR HUB
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
RIMS
27.5" alloy, 20mm depth, 30mm internal width
INNER TUBES
Presta, 40mm valve
FRONT TYRE
Butcher, GRID casing, GRIPTON® compound, 2Bliss Ready, 27.5 x 2.6"
REAR TYRE
Butcher, GRID casing, GRIPTON® compound, 2Bliss Ready, 27.5 x 2.6"
CRANKSET
Praxis, 2D cold-forged alloy, custom offset, 165mm
CHAINRINGS
32T, custom steel
SHIFT LEVERS
Shimano SLX, 11-speed
REAR DERAILLEUR
Shimano XT, Shadow Plus, GS cage, 11-speed
CASSETTE
Shimano SLX, 11-speed, 11-46t
CHAIN
KMC X11ET, 11-speed w/ Missing Link™
FRONT BRAKE
SRAM Guide RE, 4-piston caliper, hydraulic disc, 200mm
REAR BRAKE
SRAM Guide RE, 4-piston caliper, hydraulic disc, 200mm
HANDLEBARS
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 27mm rise, 800mm width
GRIPS
Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM
Specialized Trail, 3D-forged alloy, 4-bolt, 6-degree rise, 45mm
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SRL LE lever, 34.9mm, S: 125mm, M/L/XL: 150mm of travel
SEAT BINDER
Alloy, 38.6mm
MOTOR
Specialized 1.2E, custom Rx Trail-tuned motor, 250W nominal
UI/REMOTE
Trail Handlebar Remote, motor mode switch & walk-assist
BATTERY
Specialized M1-460, integrated Trail Display, ANT+/Bluetooth® module, 460Wh
CHARGER
Custom Specialized 42V2A Charger w/ Rosenberger plug, AC power cord included
WIRING HARNESS
Custom Specialized wiring harness
